HP DesignJet 1055CM Printer C6075A

Options for C6075A:

Refurbished	$2,532.47
Recertified	$3,311.69

Status: Available
Condition: OEM

Your Price: RFQ

Printer Parts
Printer Information
Related Models

Air Pressure System

C6072-60016 - Air pressurization system (APS) - Includes pump, valve, pressure sensor, and APS housing

C6074-60387 - Air pressurization system (APS) - Includes pump, valve, pressure sensor, and APS housing

C6072-60387 - Air pressurization system (APS) - Includes pump, valve, pressure sensor, and APS housing

C6072-60199 - Cutter actuator arm

C6074-60384 - CRG Base for HP DesignJet 1055 Series

C6072-60198 - Carriage drive belt kit for Hewlett-Packard designJet plotters includes belt cleaning sponges and synthetic oil.

C6072-60198_Belt - Carriage drive belt for Hewlett-Packard designJet plotters includes belt and pulley.

Bracket

C6072-60188 - Rear cover mounting bracket kit - Includes left and right brackets

Brake

C6072-60156 - Right roll feed brake - Installed in right roll feed module

C6072-60157 - Left roll feed brake - Installed in left roll feed module

C6074-60391 - Right roll feed brake - Installed in right roll feed module

C6074-60392 - Left roll feed brake - Installed in left roll feed module

Bushing

C4704-40084 - Rear slider rod bushing - Spring loaded

Cable

C2950A - IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long

C2951A - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m (9.8ft) long

C6072-60393 - Trailing cable for HP DesignJet Jet Plotters, attaches to carriage unit - 36 inch cable kit with 3 cables

C6074-60418 - Trailing cable for HP DesignJet Jet Plotters, attaches to carriage unit - 36 inch cable kit with 3 cables, only trailing cables included.

5063-1256 - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long

5063-1257 - IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 3.0m (9.8ft) long

C6072-60196 - Trailing cable for HP DesignJet Jet Plotters, attaches to carriage unit - 36 inch cable kit with 3 cables, only trailing cables included.

Canvas

Q1718A - Canvas paper (140 gsm) - 91.4cm (36in) x 10.7m (35ft) roll (USA)

Q1724A - Canvas paper (180 gsm) - 91.4cm (36in) x 10.7m (35ft) roll (USA)

C6771A - Studio canvas (368 gsm) - 91.4cm (36in) x 10.7m (35ft) roll - For regular ink or UV resistant ink

C7966A - Canvas with matte finish - 61cm (24in) x 10.7m (35ft) roll (USA)

C7967A - Canvas with matte finish - 91.4cm (36in) x 10.7m (35ft) roll (USA)

Carriage

C6072-60147 - Carriage assembly kit - Includes carriage, carriage cutter assembly, and line sensor - Does not include cable

C6072-69147 - Carriage assembly kit - Includes carriage, carriage height tool cutter assembly, and line sensor - Does not include cable

C6074-60388 - Carriage assembly kit - Includes carriage, carriage height tool cutter assembly, and line sensor - Does not include cable

C6074-69388 - Carriage assembly kit - Includes carriage, carriage height tool cutter assembly, and line sensor - Does not include cable

C6071-60032 - Carriage assembly kit - Includes carriage, carriage cutter assembly, and line sensor - Does not include cable

Cleaner

C4820-60015 - Black printhead cleaner

C4821-60005 - Cyan printhead cleaner

C4822-60059 - Magenta printhead cleaner

Clutch

C6072-60151 - Clutch assembly - Includes lever, 2 gears, a spring, and the shaft that they ride on

Control Panel

C6072-60175 - FRONT PANEL SEV-RCFront panel assembly - Includes front panel cable (has 4 buttons Cancel, print quality button, form feed button, and color button).

Cover

C6072-60165 - Right cover - Includes front panel cable - Does not include front panel assembly or aerosol fan

C6072-60167 - Left cover - Covers the ink tube system and has a door to access the ink cartridges

C6072-60168 - Top cover - Covers the top of the print mechanism (Not the window)

C6072-60169 - Back cover - Includes blank serial number label

C6072-60170 - Back EMC cover - Installs between the rear cover and the print mechanism

C6072-60171 - Left rear cover kit - Covers electronics module near the DIMM cover - Includes ferrite and clip

C6072-60172 - Right rear cover - Covers the end of the electronics module that is not near the DIMM cover

C6072-60176 - DIMM cover - Covers the DIMM sockets in the electronics module

C6072-60177 - EIO cover - Used when an EIO slot is empty

C6074-60275 - Media bin cover - Used to protect high gloss photo paper from scraches caused by contact with the media bin

C6074-60396 - Right cover - Includes front panel cable - Does not include front panel assembly or aerosol fan

Cross Brace

C6072-60185 - Cross-brace - Brace that connects and supports the two stand legs

Cutter

C6072-60200 - Cutter assembly kit - Includes mounting hardware - Installed under carriage assembly

C6074-60404 - Cutter assembly kit - Includes mounting hardware - Installed under carriage assembly

Deflector

C6071-60148 - Tail deflectors

C6079-60019 - Media deflector - Rod used when optional take-up reel is installed

C6072-60159 - Vacuum/aerosol fan assembly - Includes the fan and air flow guide

C6074-60394 - Vacuum/aerosol fan assembly - Includes the fan and air flow guide

C6072-60910 - Aerosol Fan Assembly, sits inside right cover assembly - below control panel.(for Vacuum fan C6072-60159)

51642A - Polyester matte film - 61cm (24in) x 36.6m (120ft) roll

51642B - Polyester matte film - 91.4cm (36in) x 36.6m (120ft) roll

C6761A - 3M 8519CP lustre (Semi-gloss) overlaminate - 91.4cm (36in) x 22.9m (75ft) roll - Vinyl with pressure sensitive adhesive backing - Used to protect 3M 8522CP opaque imaging media

C6762A - 3M 8520CP matte overlaminate - 91.4cm (36in) x 22.9m (75ft) roll - Vinyl with pressure sensitive adhesive backing - Used to protect 3M 8522CP opaque imaging media

C6794A - Durable Imaging glossy UV media - For UV ink only - 91.4cm (36in) x 30.5m (100ft) roll

C3875A - Clear film (4 mil) - 91.4cm (36in) x 22.9m (75ft) roll

C3876A - Clear film (4 mil) - 61cm (24in) x 22.9m (75ft) roll

C7909A - Double matte eraseable film - 61cm (24in) x 38.1m (125ft) roll (USA)

C7910A - Film (Matte) for DesignJet 2000, DesignJet 2500, DesignJet 3000, DesignJet 3500

C7911A - Film (Matte) for DesignJet 2000, DesignJet 2500, DesignJet 3000, DesignJet 3500

C7955A - Film (Opaque) for DesignJet 2800, DesignJet 3800, DesignJet 3000, DesignJet 5000 Series

C7956A - Film (Opaque) for DesignJet 5000 Series, DesignJet 800 Series, DesignJet 1055 Series, DesignJet 500

Q1908A - Film (Adhesive) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1914A - Film (Transparency) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1915A - Film (Transparency) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1958A - Film (Glossy) for DeskJet 3940 Series, DeskJet 660 Series, DeskJet 6500 Series, DeskJet 420C

C3835S - HP Premium Trans Film 250 Sht Value Pack

Firmware

C6074-60469 - Firmware DIMM - Firmware version A.52.02 plus firmware with postscript.

C6075-60269 - Electronics module assembly - For the Designjet 1000 Series and the multi-roll feeder

C6075-69269 - Electronics module assembly - For the Designjet 1000 Series and the multi-roll feeder

C6075-60282 - Firmware DIMM FW A.52.02 PS FLASH SERV - RC plus firmware with postscript.

C6075-60286 - Firmware DIMM (Revision A.52.02)plus firmware with postscript.

C6075-60284 - Firmware Dimm (Revision A.52.02)for HP Designjet 1050c 1055cm plotters.

C6072-60182 - Foot assembly (includes casters) - Mounts to the bottom of the stand legs (two used)

Front Panel

C6074-60398 - FRONT PANEL SEV-RCFront panel assembly - Includes front panel cable ( has cancel button, print quality button, form feed button, and color button).

Guide

C6072-60163 - Drive roller guide (Guide is the full width of the plotter) - Includes the drive roller guide and media guide strip

C6072-60189 - Center guide and media sensor (Guide is the full width of the plotter)

C6072-60194 - Front guide assembly (U-shaped)

C6072-60195 - Tube guide assembly

C6072-60011 - Media Guide Strip For Hewlett-packard (HP) Printers - Installed Between the Drive Roller and

C6074-60401 - Center guide and media sensor (Guide is the full width of the plotter)

C6074-60468 - Center guide and media sensor (Guide is the full width of the plotter)

Handle

C6072-60152 - Handle for automatic roll sheet switch (ARSS) assembly

Hard Drive

C6075-60005 - 3.2GB hard drive (DesignJet EIO Font/Print Job Storage)

C6075-69005 - 3.2 GB Hard Drive (DSNJT 1050C/1055CM) - DesignJet/ Plotter EIO font/print job storage hard drive.

Hardware

C6071-60155 - Automatic roll sheet switch (ARSS) parts kit - ARSS torsion spring, ARSS axle gear, ARSS switch lever

Holder

C6071-60154 - Quick reference guide holder

Ink Supply Station

C6074-60386 - Ink Supply Station (ISS) - Has four slots for ink cartridges

Ink System

C6072-60145 - Ink Tube System - Designjet 1050C 1055CM Ink Tube System unit.

C6074-60342 - Ink Tube System - Designjet 1050C 1055CM Ink Tube System unit.

C6074-60415 - Ink Tube System - Designjet 1050C 1055CM Ink Tube System unit.

C6072-60180 - Hardware kit for printer stand - Includes screwdriver and screws

C6071-60242 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Korean)

C6071-60243 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Taiwan)

C6071-60244 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (German)

C6071-60245 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (French)

C6071-60246 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Spanish)

C6071-60247 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Italian)

C6071-60249 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Portuguese)

C6071-60250 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Chinese)

C6072-60368 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (Japanese)

C6074-60383 - Automatic roll sheet switch (ARSS) parts kit - ARSS torsion spring, ARSS axle gear, ARSS switch lever

C6071-60241 - Manual kit - Includes setup guide, quick reference guide, and assembly instructions (English)

Label

C4704-00119 - Adobe PostScript label

Leak Detector

C6071-60168 - Ink leak detector system (LDS) - Includes ink collector, leak sense cable, leak sense cable clip

C6072-60184 - Leg assembly - Side support for the printer - Does NOT include the foot assembly

Light

C4955-80013 - Printhead/Cleaner Light Magent

Lubricant

6040-0911 - Special lubricating oil - For carriage slider rod surface - (syringe with 35cc oil)

6040-0858 - Lubricant : Special lubricating oil - For carriage slider rod surface - 4oz (113g) plastic bottle of synthetic oil

C3190-60155 - Grease - GREASE APPLICATION KITGrease - For helical gear (Drive roller gear)

C6074-60460 - Grease - GREASE APPLICATION KITGrease - For helical gear (Drive roller gear)

6040-0855 - SYNTHETIC OIL (4oz Plastic Bottle) Front and Rear Slider Rods Synthetic oil - One plastic bottle of 3.5oz / 118.29 ML

C6071-60177 - Oil applicator (black handle no longer included)-Lubricant Oil 10ml and ink / toner cleaning cloth for Hewlett Packard Designjet Plotters.

C6072-60047 - Overdrive oil kit

21030 - Grease - GREASE APPLICATION KITGrease - For helical gear (Drive roller gear)

Maintenance Kit

C6072-60395 - Maintenance Kit - All major wearable parts including, Ink Tube System, Carriage Trailing Cable Kit, Carriage Motor, Carriage Drive Belt.

C6074-60420 - Maintenance Kit - All major wearable parts including, tubes, trailing cable with retainer and clip, spitoon foam, idler pulley, oil applicator, carriage foam, belt, drop detector, ISS connector cable, scan motor, carriage and needed fastener hardware

Manual

C6071-60344 - DesignJet 1050C/1055CM documentation CD-ROM (German) - Contains on-screen movies and users documentation

C6071-60345 - DesignJet 1050C/1055CM documentation CD-ROM (French) - Contains on-screen movies and users documentation

C6071-60346 - DesignJet 1050C/1055CM documentation CD-ROM (Spanish) - Contains on-screen movies and users documentation

C6071-60347 - DesignJet 1050C/1055CM documentation CD-ROM (Italian) - Contains on-screen movies and users documentation

C6071-60349 - DesignJet 1050C/1055CM documentation CD-ROM (Portuguese) - Contains on-screen movies and users documentation

C6071-90102 - DesignJet 1050C and 1055CM users guide (Korean)

C6071-90103 - DesignJet 1050C and 1055CM users guide (Taiwanese)

C6071-90104 - DesignJet 1050C and 1055CM users guide (German)

C6071-90105 - DesignJet 1050C and 1055CM users guide (French)

C6071-90106 - DesignJet 1050C and 1055CM users guide (Spanish)

C6071-90107 - DesignJet 1050C and 1055CM users guide (Italian)

C6071-90108 - DesignJet 1050C and 1055CM users guide (Japanese)

C6071-90109 - DesignJet 1050C and 1055CM users guide (Portuguese)

C6071-90110 - DesignJet 1050C and 1055CM users guide (Chinese)

C6071-90111 - DesignJet 1050C and 1055CM users guide (Czech)

C6071-90112 - DesignJet 1050C and 1055CM users guide (Greek)

C6071-90113 - DesignJet 1050C and 1055CM users guide (Hungarian)

C6071-90114 - DesignJet 1050C and 1055CM users guide (Polish)

C6071-90115 - DesignJet 1050C and 1055CM users guide (Russian)

C6071-90117 - C6079A take-up reel users guide - No longer available - See the DSNJT 1050C and 1055CM users gu

C6072-60281 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (English)

C6072-60301 - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (English)

C6075-60201 - DesignJet 1050C/1055CM PostScript driver software CD-ROM - For Windows 95/98/NT 4.0 and Apple/Macintosh - PostScript upgrade MUST be installed in 1050C first - Multilingual

C6079-90002 - C6079A take-up reel users guide (Korean)

C6079-90003 - C6079A take-up reel users guide (Taiwanese)

C6079-90004 - C6079A take-up reel users guide (German)

C6079-90005 - C6079A take-up reel users guide (French)

C6079-90006 - C6079A take-up reel users guide (Spanish)

C6079-90008 - C6079A take-up reel users guide (Japanese)

C6079-90009 - C6079A take-up reel users guide (Portuguese)

C6079-90010 - C6079A take-up reel users guide (Chinese)

C6079-90011 - C6079A take-up reel users guide (Czechoslovakian)

C6079-90012 - C6079A take-up reel users guide (Greek)

C6079-90013 - C6079A take-up reel users guide (Hungarian)

C6079-90014 - C6079A take-up reel users guide (Polish)

C6079-90015 - C6079A take-up reel users guide (Russian)

C6079-90017 - C6079A take-up reel users guide (Turkish)

C7779-60041 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (English)

5959-9734 - Manual for DesignJet 2000, DesignJet 2500, DesignJet 430, DesignJet 450

C6071-60341 - DesignJet 1050C/1055CM documentation CD-ROM (English) - Contains on-screen movies and users documentation

C6071-90000 - Manual for DesignJet 1050 Series, DesignJet 1055 Series

C6071-90101 - Manual for DesignJet 1050 Series, DesignJet 1055 Series

C6071-90241 - DesignJet 1050C and 1055CM Quick Reference Guide (English)

C6079-90001 - Manual for DesignJet 1050 Series, DesignJet 1055 Series

Media Bin

C6072-60208 - Media bin - Between printer stand legs

Memory

C6074-60003 - 16MB EDO (Extended Data Output) DRAM DIMM memory module

C6074-60004 - 32MB EDO (Extended Data Output) DRAM DIMM memory module

C6074-60005 - 64MB EDO (Extended Data Output) DRAM DIMM memory module

C6252A - 32MB EDO (Extended Data Output) DRAM DIMM - For DesignJet 1000 series printers

C6251A - 16MB EDO (Extended Data Output) DRAM DIMM - For DesignJet 1000 series printers

C6258A - 64MB EDO (Extended Data Output) DRAM DIMM - For Hewlett Packard DesignJet Plotters.

C6075-69022 - Firmware DIMM (Revision A.01.07) - Mounts in the Electronics

Module

C6072-60146 - Electronics module board for HP designJet plotters 1050C and 1055CM units. (for Plus version order C6075-69280).

C6072-69146 - Electronics module - Contains power supply, main logic board and cooling fan. (order just board C6071-60001).

C6075-69280 - Electronics module assembly for Plus models- For the C6075-69280 DesignJet 1055cm PLUS Electronics Module (non-plus, order C6072-60146).

C6074-60408 - Electronics module base - Includes cooling fan and power supply.

C6075-60280 - Electronics module assembly (for Plus models) - For the DesignJet 1000 Series and the multi-roll feeder

C6074-69436 - Hewlett Packard Electronic Module for Designjet 1050C+ and 1055CM+, Electronic module includes formatter pc board and power supply (enclosure).

C6074-69460 - Hewlett Packard Electronic Module for Designjet 1050C+ and 1055CM+, Electronic module includes formatter pc board and power supply (enclosure).

C6074-60436 - Hewlett Packard Electronic Module for Designjet 1050C+ and 1055CM+, Electronic module includes formatter pc board and power supply (enclosure).

Motor

C6072-60160 - Paper-axis motor - Includes helical gear and grease - Motor that provides power to feed paper for printing process

C6072-60394 - Carriage motor - Includes pulley

C6074-60395 - Paper-axis motor - Includes helical gear and grease - Motor that provides power to feed paper for printing process

C6074-60419 - Carriage motor - Includes pulley

C6095-60261 - HP Designjet Plotter Scan Axis Motor, Paper motor provides power to feed paper for printing process

Mount

C6079-60017 - Left take-up reel spindle mount assembly

C6079-60018 - Right take-up reel spindle mount assembly

NamePlate

C6075-00001 - Nameplate - DesignJet 1055CM

6040-0990 - Special lubricating oil - For carriage slider rod surface - (5cc oil)

Overlay

C6074-60241 - Front panel overlay (English)

C6074-60242 - Front panel overlay (Korean)

C6074-60243 - Front panel overlay (Taiwanese)

C6074-60244 - Front panel overlay (German)

C6074-60245 - Front panel overlay (French)

C6074-60246 - Front panel overlay (Spanish)

C6074-60247 - Front panel overlay (Italian)

C6074-60248 - Front panel overlay (Japanese)

C6074-60249 - Front panel overlay (Portuguese)

C6074-60250 - Front panel overlay (Chinese)

Paper

Q1397A - Universal Bond Paper - 91.4cm (36in) x 30.5m (100ft) roll

Q1739A - Heat Transfer Paper - 91.4cm (36in) x 30.5m (100ft) roll (USA)

Q1909A - Polypropylene Adhesive Back print media - 106.7cm (42in) x 21.3m (70ft) roll

Q1426A - Hewlett Packard Supplies HP paper - high-gloss photo paper - Roll A1 (24 in x 100 ft) - 179 g/m2

Q1398A - Hewlett Packard Supplies HP paper - bond paper - Roll (42 in x 150 ft) - 80 g/m2

Q1721A - Embossed Paper (140 gsm) - 91.4cm (36in) x 10.7m (35ft) roll (USA)

C1860A - HP Bright white InkJet paper - 61cm (24in) x 45.7m (150ft) roll

C1861A - HP Bright white InkJet paper - 91.4cm (36in) x 45.7m (150ft) roll

C6019B - Coated paper (98 gsm) - 61cm (24in) x 45.7m (150ft) roll (USA, Canada, and Latin America)

C6020B - Coated paper (98 gsm) - 91.4cm (36in) x 45.7m (150ft) roll (USA, Canada, and Latin America)

C6021B - Heavyweight coated paper - 61cm (24in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6022B - Heavyweight coated paper - 91.4cm (36in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6023A - Semi-gloss photo paper - 61cm (24in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6024A - Semi-gloss photo paper - 91.4cm (36in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6025A - High gloss photo paper - 61cm (24in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6026A - High gloss photo paper - 91.4cm (36in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6029C - Heavyweight coated paper - 61cm (24in) x 30.5m (100ft) roll - For regular or UV resistant ink

C6030C - Heavyweight coated paper - 91.4cm (36in) x 30.5m (100ft) roll - For regular or UV resistant ink

C6559B - Coated paper (98 gsm) - 106.7cm (42in) x 45.7m (150ft) roll (USA, Canada, and Latin America)

C6560B - Coated paper (98 gsm) - 137.2cm (54in) x 45.7m (150ft) roll (USA, Canada, and Latin America)

C6561B - Heavyweight coated paper - 106.7cm (42in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6562B - Heavyweight coated paper - 137.2cm (54in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6563A - Semi-gloss photo paper - 106.7cm (42in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6564A - Semi-gloss photo paper - 137.2cm (54in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6565A - High gloss photo paper - 106.7cm (42in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6566A - High gloss photo paper - 137.2cm (54in) x 30.5m (100ft) roll (USA, Canada, and Latin America)

C6786A - Banner paper with Tyvek (140 gsm) - UV ink only - 61cm (24in) x 15.2m (50ft) roll

C6787A - Media for HP Q1279A Banner paper with Tyvek (140 gsm) - UV ink only - 91.4cm (36in) x 15.2m (50ft) roll

C6789A - Banner paper with Tyvek (140 gsm) - UV ink only - 91.4cm (36in) x 15.2m (50ft) roll

C6810A - Bright white InkJet paper - 91.4cm (36in) x 91.4m (300ft) roll

C6813A - High gloss photo paper - 61cm (24in) x 30.5m (100ft) roll

C6814A - High gloss photo paper - 91.4cm (36in) x 30.5m (100ft) roll

C6980A - Coated paper (98 gsm) - 91.4cm (36in) x 91.4m (300ft) roll (USA, Canada, and Latin America)

C3859A - Paper - transparencies, continuous forms - Roll A0 91.4 cm x 45.7 m) - 67 g/m2 - 1 pcs.

C3860A - Translucent bond paper - 61cm (24in) x 45.7m (150ft) roll

C3868A - Natural tracing paper - 91.4cm (36in) x 45.7m (150ft) roll

C3869A - Natural tracing paper - 61cm (24in) x 45.7m (150ft) roll

C7922A - Basic Bond paper - 106.7cm (42in) x 45.7m (150ft) roll

C7923A - Basic heavyweight paper - 61cm (24in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C7924A - Basic Heavyweight Paper - 91.4cm (36in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C7919A - Basic bond paper - 61cm (24in) x 45.7m (150ft) roll

C7921A - Basic bond paper - 91.4cm (36in) x 45.7m (150ft) roll

C6035A - Bright white InkJet paper - 61cm (24in) x 45.7m (150ft) roll

C6036A - Bright white InkJet paper - 91.4cm (36in) x 45.7m (150ft) roll

C8281A - Basic coated paper - 61cm (24in) x 45.7m (150ft) roll (USA and Asia/Pacific)

C8282A - Basic coated paper - 91.4cm (36in) x 45.7m (150ft) roll (USA and Asia/Pacific)

C8310A - Basic photo satin paper - 61cm (24in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C8311A - Basic photo satin paper - 91.4cm (36in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C8315A - High gloss photo paper - 61cm (24in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C8316A - High gloss photo paper - 91.4cm (36in) x 30.5m (100ft) roll (USA and Asia/Pacific)

C6019A - Paper (Coated) for DesignJet 2000, DesignJet 3000, DesignJet 1055 Series, Designjet 120

C7873A - Paper (Coated) for DesignJet 1055 Series, DesignJet 5000 Series, DesignJet 500, DesignJet 800 Series

C7874A - Paper (Photo) for DesignJet 1050 Series, DesignJet 1055 Series, DesignJet 500, DesignJet 800 Series

C7946A - Paper (Matte) for DesignJet 2000, DesignJet 2500, DesignJet 3000, DesignJet 3500

C7949A - Outdoor billboard paper - The back of the paper is blue in color - 91.4cm (36in) x 30.5m (100ft) roll (USA)

C7952A - Paper (Satin) for DesignJet 2000, DesignJet 2500, DesignJet 3000, DesignJet 3500

Q1396A - Paper for DesignJet 1055 Series, DesignJet 800 Series, DesignJet 130 Series, DesignJet 500. Bond Paper - 24 inch x 150.

Q1412A - Paper (Coated) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1413A - Paper (Coated) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1416A - Paper (Coated) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1419A - Paper (Coated) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1420A - Paper (Photo) for Designjet 820 MFP Series, DesignJet T1100 T160 printer series, DesignJet 2000, DesignJet 3000

Q1733A - Paper for DesignJet 800 Series, DesignJet 1055 Series, DesignJet 5000 Series, DesignJet 500

Q1736A - Paper (Matte) for DesignJet 2000, DesignJet 2500, DesignJet 3000, DesignJet 3500

Q1903A - Paper (Matte) for DesignJet 2000, DesignJet 1050 Series, DesignJet 1055 Series, DesignJet 5000 Series

Q1904A - Paper (Matte) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1906A - Paper (Matte) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1907A - Paper (Matte) for DesignJet 2000, DesignJet 3000, DesignJet 1050 Series, DesignJet 1055 Series

Q1918A - Paper (Fabric) for DesignJet 500, DesignJet 5000 Series, DesignJet 1055 Series, DesignJet 800 Series

Q1919A - Paper (Fabric) for DesignJet 500, DesignJet 2000, DesignJet 1055 Series, DesignJet 5000 Series

Q1920A - Paper (Fabric) for DesignJet 1055 Series, DesignJet 800 Series, DesignJet 5000 Series, DesignJet 500

Q1961A - Paper (Coated) for DesignJet 750, DesignJet 1050 Series, DesignJet 1055 Series, DesignJet 5000 Series

Q1962A - Paper (Coated) for DesignJet 750, DesignJet 1050 Series, DesignJet 1055 Series, DesignJet 5000 Series

Q6569A - Premium Plus Soft-Gloss Photo Paper (Matte) - A size (8.5 x 11-inches) - 25 sheets (North America)

PC Board

J3111-69001 - JetDirect 600N EIO internal print server 10Base-T, 10BASE-2, and LocalTalk LAN interface board - Has one RJ-45, BNC, and 8-pin DIN connector;Click to order the functional equivalent: J4135-61001

J4167-69001 - JetDirect 600N EIO internal print server token ring LAN interface board - Has one RJ-45 and DB-9 connector

C6071-60001 - Main Logic PC board DesignJet 1050C 1055CM Main Logic Board A VERSION - sm board (has 2 connectors) (for Plus series try C6071-60190). For inch B inch version order C6074-69406, has connector and thermister,

Pinch Assembly

C6072-60009 - Pinch assembly - Includes pinch cam, pinch rollers, springs

C6074-60385 - Pinch assembly - Includes pinch cam, pinch rollers and springs

Platen

C6072-60161 - Center platen assembly - Includes overdrive rollers and screws

C6072-60162 - Front platen assembly - Long, curved item without rollers - Includes platen and screws

C6072-60186 - Rear platen assembly

C6074-60457 - Center platen assembly - Includes overdrive rollers and screws

C6074-67801 - Front platen assembly - Long, curved item without rollers - Includes platen and screws

Power Cord

8120-0698 - Power cord (Black) - 18 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (for 220V in the USA and Canada)

8120-1378 - Power cord (Jade Gray) - 18 AWG, 2.3m (7.5ft) long - Has straight (F) C13 receptacle (for 120V in USA, Canada, Latin America, Korea, Taiwan, Thailand, Spain, Brazil, and Vietnam)

8121-0877 - Power cord (Black) - 18 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (for 220V in the USA and Canada)

Power Supply

C6074-60405 - Power supply unit for Hewlett Packard Designjet Plotters.

Print Server

J3111-61001 - JetDirect 600N EIO internal print server 10Base-T, 10BASE-2, and LocalTalk LAN interface board - Has one RJ-45, BNC, and 8-pin DIN connector

J3112-69001 - JetDirect 600N EIO internal print server token ring LAN interface board - Has one RJ-45 and DB-9 connector

J6057A - JetDirect 615N internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector

J7934-61001 - JetDirect 620N Ethernet Print Server, internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector.

J7934-69001 - JetDirect 620N Ethernet Print Server, internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector.

J7934A - JetDirect 620N Ethernet Print Server, internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector.

J6057-69011 - JetDirect 615N internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector.

J7934-61011 - JetDirect 620N Ethernet Print Server, internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector.

Roller

C6072-60191 - Paper drive roller assembly - Includes drive roller, roller gear, and roller bracket

C6072-60154 - Entry roller - Large, long roller at front of printer

C6074-60403 - Paper drive roller assembly - Includes drive roller, roller gear, and roller bracket

Rollfeed Assembly

C6072-60155 - Right roll feed module

C6072-60158 - Left roll feed module

C6074-60390 - Right roll feed module

C6074-60393 - Left roll feed module

C6071-40058 - Right roll feed module

Screw

0624-0795 - Screw Filter

0515-2200 - Screw Tptt-AP MOQ=Mult

Sensor

C6072-60190 - Media sensor for HP DesignJet 1050C Series

C6072-60179 - Drop detector (sensor) assembly - Includes spittoon foam - Installed in service station assembly

C6079-60016 - Sensor assembly for take-up reel

C6074-60402 - Media sensor for HP DesignJet 1050C Series

C6074-60400 - Drop detector (sensor) assembly - Includes spittoon foam - Installed in service station assembly

Service Parts

Q1254-60025 - English/korean for HP 32054F

C6020A - HP Coated Paper 36-inch x 150 ft 98 gsm

C7886A - LF Proofing Gloss

Q1745A - Paper Backed Fabric Polyester - 91.4cm (36in) x 10.1m (33ft) roll (USA)

Q1748A - Paper Backed Fabric Silk Satin - 91.4cm (36in) x 10.1m (33ft) roll (USA)

Service Station

C6072-60015 - Ink Supply Station (ISS) - Has 4 slots for ink cartridges

C6072-60178 - Service station assembly - Includes drop detector assembly

C6074-60399 - Service station assembly - Includes drop detector assembly

Software

C6071-60368 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Japanese)

C6072-60284 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (German)

C6072-60285 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (French)

C6072-60286 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (Spanish)

C6072-60287 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (Italian)

C6072-60304 - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (German)

C6072-60305 - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (French)

C6072-60306 - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (Spanish)

C6072-60307 - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (Italian)

C7779-60040 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Chinese)

C7779-60042 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Korean)

C7779-60043 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Taiwanese)

C7779-60044 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (German)

C7779-60045 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (French)

C7779-60046 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Spanish)

C7779-60047 - ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series (Italian)

Spindle

C6072-60126 - E/A0 rollfeed spindle assembly - Includes end caps 36in E-size. Spindle for HP Designjet Plotters.

C6078A - E/A0 spindle kit for DesignJet 1000 series printer

C6072-60125 - E/A0 rollfeed spindle assembly - Includes end caps 36in E-size. Spindle for HP Designjet Plotters.

C6072-60153 - E/A0 rollfeed spindle assembly - Includes end caps 36in E-size. Spindle for HP Designjet Plotters.

Strip

C6072-60197 - Encoder strip for HP DesignJet 1050C Series

C6072-60391 - Media guide strip For Hewlett-packard (HP) Printers

Support

C6072-60192 - Left arc assembly

C6072-60193 - Right arc assembly

Switch

C6072-60150 - Automatic roll sheet switch (ARSS) assembly - Small, long roller and housing - Used to feed cut sheet media

C6074-60389 - Automatic roll sheet switch (ARSS) assembly - Small, long roller and housing - Used to feed cut sheet media

Take Up Assembly

C6079A - Take-up reel kit for HP DesignJet 1000 Series - Allows printed media to be automatically rolled while printing - Includes spindle, spindle drive, media deflector, and documentation

Tensioner

C6072-60149 - Tensioner assembly - Includes pulley assembly, pulley spring, wedge, cutter actuator arm, and tensioner housing

C6071-60153 - Carriage interconnect wiper (flex cleaner) - Handheld tool used to clean the electrical contacts for the printheads

C6071-60166 - Carriage height tool

C6072-60183 - Printer stand tray - Mounted between the feet of printer

C6072-60173 - Left trim - On the left arc

C6072-60174 - Right trim - On the right arc

C6074-60397 - Right trim - On the right arc

Vellum

C3861A - Vellum - 91.4cm (36in) x 45.7m (150ft) roll

C3862A - HP Vellum Paper is ideal for reproducible final drawings. Offers crisp, archivable line drawings and sharp text and uniform solid areas. 75-g/m² (20-lb) weight provides excellent handling and durability. The HP Designjet printing solution—printer.

Vinyl Adhesive

C6775A - Colorfast adhesive vinyl (328 gsm) - 91.4cm (36in) x 12.2m (40ft) roll - For regular ink or UV-resistant ink

Weight

C6021A - HP Heavyweight Coated 24-inch x 100 roll

C6022A - HP Heavyweight Coated 36-inch x 100 roll

Window

C6072-60164 - Lift-up viewing window
